The Application Notes listed below are provided by the manufacturer of the Uvscale film, namely Fuji Film Japan.
Of course, the list below is not intended to be exhaustive, as the number of applications compatible with Uvscale film is indeed significant and continually increasing.
Therefore, it is presented as a brief overview of the most significant applications. In this specific area, we believe it is useful to highlight that
many of these applications are conceptually (or sometimes entirely) transferable to many other similar contexts, which means that the applications represented
are virtually much more numerous. With reference to the Application Notes listed below, they can be viewed in PDF format by simply clicking the
respective link with the left mouse button. However, if interested, you can also save a copy of each document by right-clicking the hyperlink and selecting
"Save target as." For proper viewing of the documents, the Adobe Acrobat Reader™ utility is required. Spare remains at your disposal for any further
clarification that may be necessary.
Application Notes by Fuji Film: list of available documents
The Uvscale film allows for the verification of the correct distribution and intensity of ultraviolet light irradiated on objects and components in relation to UV
coating processes, ensuring proper drying and curing. Such processes are used for automotive parts, electronic products, and materials for flooring and
furnishings. Uvscale makes it easy to verify the uniform distribution of UV light across all treated areas.
Uvscale allows for the verification of the correct distribution and intensity of ultraviolet light irradiated on objects and products in relation to UV printing
processes, ensuring proper drying and curing. Such processes are used for printing on paper rolls, coatings for packaging, electronic boards, cans, and more.
Uvscale therefore makes it easy to verify the uniform distribution of UV light across all treated areas.
Various industrial sectors, especially in microelectronics, use coating and adhesive processes with resins that dry and cure when exposed to ultraviolet light.
These include, for example, the coating and adhesion of liquid crystal display panels and certain treatments for hard disk parts. UVscale thus allows for easy
verification of the uniform distribution of UV light across all treated areas.
Numerous production processes involve the deposition and subsequent treatment of coating resins that dry and cure when exposed to ultraviolet light. In this context,
UV irradiation chambers, through which the processing product passes, do not always offer suitable and accessible spaces for using light meters. UVscale,
however, allows for easy verification of irradiation distribution through simple insertion.
Pellicola Uvscale: Application Note n°. 05 - Verification of Sterilization in Packaging
A typical application in the food sector involves verifying the correct sterilization of containers and caps using ultraviolet light. By employing the UV-sensitive
film UVscale, it is possible to ensure adequate and uniform distribution of ultraviolet irradiation, thus guaranteeing the best possible sterilization effect.
This is achieved simply by placing the film in areas that are normally intended to be irradiated.
The UV-sensitive film UVscale has proven significantly useful in assessing the quantity and distribution of ultraviolet light irradiated in UV photo-curing resin
molding systems that use nanoimprinting technology. Notable applications include electronic components, LCD materials, LED components, and films for solar
batteries.
This application is particularly specific to the semiconductor microelectronics sector, as it pertains to equipment involved in wafer back grinding, etching,
and dicing processes, which typically operate with ultraviolet emissions. By using the UV-sensitive film UVscale, it is possible to easily verify the uniformity
and intensity of the UV light applied during these treatments.
In the field of UV inkjet printing systems, whether small or large, the UV-sensitive film UVscale allows for easy and quick verification of the intensity and
correct distribution of ultraviolet irradiation. It overcomes potential difficulties in accessing UV emission areas, which may not always provide adequate
and accessible space for using devices like light meters. UVscale can be used simply by direct insertion.
For applications where it is necessary to verify the axis of ultraviolet emission, such as the calibration of camera lenses, DVD pickup lenses, or hard disk
components, while also assessing the intensity and distribution of the irradiation, the UV-sensitive film UVscale has proven particularly advantageous.
It helps ensure the absence of deviations, which otherwise would lead to poor performance.
Pellicola Uvscale: Application Note n°. 10 - Verification of Reflectors for UV Lamps
This Application Note documents the performance verification of reflectors intended for use with ultraviolet sources. This can be carried out both during the
design phase and for quality inspection purposes, as well as during maintenance interventions. With the UV-sensitive film UVscale, it is possible to easily
verify the correct intensity and distribution of ultraviolet light emitted by these reflectors.
You are here: products · applications· application notes uvscale film
Fuji Uvscale Film
Application Notes by Fuji Film
Application Notes by Fuji Film: Overview
The Application Notes listed below are provided by the manufacturer of the Uvscale film, namely Fuji Film Japan. Of course, the list below is not intended to be exhaustive, as the number of applications compatible with Uvscale film is indeed significant and continually increasing.
Therefore, it is presented as a brief overview of the most significant applications. In this specific area, we believe it is useful to highlight that
many of these applications are conceptually (or sometimes entirely) transferable to many other similar contexts, which means that the applications represented
are virtually much more numerous. With reference to the Application Notes listed below, they can be viewed in PDF format by simply clicking the
respective link with the left mouse button. However, if interested, you can also save a copy of each document by right-clicking the hyperlink and selecting
"Save target as." For proper viewing of the documents, the Adobe Acrobat Reader™ utility is required. Spare remains at your disposal for any further
clarification that may be necessary.
Application Notes by Fuji Film: list of available documents
Pellicola Uvscale: Application Note n°. 01 - UV Coating Processes
Pellicola Uvscale: Application Note n°. 02 - UV Printing Processes
Pellicola Uvscale: Application Note n°. 03 - UV Coating and Adhesive Processes
Pellicola Uvscale: Application Note n°. 04 - Verification of UV Irradiation Chambers
Pellicola Uvscale: Application Note n°. 05 - Verification of Sterilization in Packaging
Pellicola Uvscale: Application Note n°. 06 - Optimization of Thermosetting Resin Molding
Pellicola Uvscale: Application Note n°. 07 - Optimization of Microelectronics Equipment
Pellicola Uvscale: Application Note n°. 08 - Optimization of UV Inkjet Printers
Pellicola Uvscale: Application Note n°. 09 - Verification of Ultraviolet Light Axiality
Pellicola Uvscale: Application Note n°. 10 - Verification of Reflectors for UV Lamps
